Lightbulb E21 Bumper Tuck

If you're like me and can't afford to buy European bumpers and the related valance bodywork, here's a cheap (free) option to rid of your E21 car of that unsightly front bumper.

Said bench/diving board that enters the street five minutes before the rest of car. HAHA!!


First, get a decent powered drill and a sharp drill bit. Can't remember what size bit I used... probably something in the 1/4" range. Also, put down some plastic, get some rubber gloves, safety goggles and/or clear plastic facemask. Lastly, a bucket. For mine, I used a friend's driveway and pulled my car onto some ramps.

When you're ready to work, remove the front bumper, like this.

I opened my hood and placed my Hella driving lights on top of the grills to keep them out of the way.

Next, a simple example of how far the 5mph. bumper shocks stick out past the car, before drilling.


Now, you're ready to drill underneath the bumper shock. Keep in mind that these shocks contain pressurized oil! Protect yourself with the above mentioned safety stuff. Place the bucket below the shock and start drilling.

Note the oil dripping into the bucket from the shock.

After drilling and working the piston in and out to remove any pressure and oil, you can see how much the shock has compressed when pushed in, fully.

Amazingly, I was able to accomplish this without using a mallet or wall, like I had previously read about on the 'Net.

At this point, I tried putting the bumper back on the car for a test fit. I wasn't happy that the black filler piece (between the valance and bumper) wasn't allowing the bumper to tuck closer. So while I already had those two halves removed, I decided to get my jigsaw out and trim an inch off.

As you can see, there is still the issue of the side bellows needing to be cut down.

Which was way easier that I had previously thought. I grabbed an old mini hand woodsaw and removed a 2" section of bellows from the center of where the ridges start on either end. That way, the finished job appears to be factory. I've never seen a front bumper tuck where I was satisfied with the bellows.

Here's what it looked like after the initial cut.

The next cut involved removing the 2" section from the part in my hand.

Then, I bolted the part of the bellows that attaches to the bumper. Made sure that the bumper was pushed all the way in. Reinstalled the driving lights. I also never cared for the side reflectors on the front bumpers (U.S. cars). So I carefully removed those. Painted them with primer, then with semi-gloss black. When dry, popped them back in.

Done!


Another view.

You might want to install a screw or bolt in each drilled hole on the bumper shocks. I was amazed at how easy and effortless this 2hr. project was. Perhaps, one day, I'll be able to afford Euro bumpers. But in the meantime, I'm happy with this and it looks like the car came this way.

I've seen other methods of doing this which included removing the shocks to drill or replacing them with welded bars. To each their own... I just wanted to share how I chose to do mine. Your results may vary. After these pictures were taken, I found some N.O.S. Hella H4 & H1 headlights at my friend's Volkswagen shop for only $25 ea. Installed 'em and LOVIN' it. Can't believe that I drove this car for three weeks with sealed beams. YUCK! Since my first car in '79, I've always had either Hella or Euro spec lighting.




__________________
Cheers,
Mark
1982 320i 5spd.
1987 Volvo 245DL Estate 5spd.
1967 Volkswagen Beetle 4spd.
Too many surfboards & skateboards to count.


Last edited by Rennsurfer; 02-11-2008 at 07:01 AM.
Rennsurfer is offline   Reply With Quote
Sponsored Links
Advertisement

Old 02-11-2008, 09:02 AM   #2 (permalink)
I am Teh Edumacator.

Teh Prof's Avatar

Join Date: May 2005
Location: ATL, London, and Barcelona
Car: 1999 Dinan 540i/6, 1995 Dinan 749
Posts: 4,520
Photos:
Teh Prof has much to be proud ofTeh Prof has much to be proud ofTeh Prof has much to be proud ofTeh Prof has much to be proud ofTeh Prof has much to be proud ofTeh Prof has much to be proud ofTeh Prof has much to be proud ofTeh Prof has much to be proud ofTeh Prof has much to be proud ofTeh Prof has much to be proud of
Send a message via AIM to Teh Prof
Good job!
__________________


1999 E39 540i/6-VF Stage 1 S/C, Dinan exhaust, Dinan strut+shock braces, Dinan ltwt flywheel + clutch, Dinan Brembo BBK, Dinan monoball, H&R Springs, Koni Yellows, M5 sways, Dinan forged 18" wheels, &c.

1995 E38 740i. Highly modded. Faster than you.

Sold 2-28-07: 1997 E36 M3/4, 8-30-05 RIP 1997 528i


Lindsay fan club member.
Teh Prof is offline   Reply With Quote
Old 02-11-2008, 01:38 PM   #3 (permalink)
Neutral Member

Rennsurfer's Avatar

Join Date: Jan 2008
Location: Near Mother Ocean, So Cal
Car: 1982 320i 5spd.
Posts: 55
Photos:
Rennsurfer is on a distinguished road
Quote:
Originally Posted by Teh Prof
Good job!
Thank you.
__________________
Cheers,
Mark
1982 320i 5spd.
1987 Volvo 245DL Estate 5spd.
1967 Volkswagen Beetle 4spd.
Too many surfboards & skateboards to count.

Rennsurfer is offline   Reply With Quote
Old 07-28-2008, 10:47 AM   #4 (permalink)
Neutral Member

82_320i's Avatar

Join Date: Jul 2008
Car:
Posts: 71
Photos:
82_320i is on a distinguished road
how or did you reconnect that front piece of the bellows to the bumper?
__________________
SNAKE
82_320i is offline   Reply With Quote
Old 07-28-2008, 11:44 AM   #5 (permalink)
Neutral Member

Rennsurfer's Avatar

Join Date: Jan 2008
Location: Near Mother Ocean, So Cal
Car: 1982 320i 5spd.
Posts: 55
Photos:
Rennsurfer is on a distinguished road
Quote:
Originally Posted by 82_320i View Post
how or did you reconnect that front piece of the bellows to the bumper?
I bolted them back onto the bumper ends exactly how they came from the factory. I only removed a couple of inches from the center section of the bellows. So, in the end, the bellows are connected at the bumper on the forward end and the rear portion remains attached to the side rubber part where the Hella reflector (now painted black) resides.

Sorry if that doesn't translate correctly. It's easier to show you in person. Guess I should have taken more detailed shots when I was doing that.
__________________
Cheers,
Mark
1982 320i 5spd.
1987 Volvo 245DL Estate 5spd.
1967 Volkswagen Beetle 4spd.
Too many surfboards & skateboards to count.

Rennsurfer is offline   Reply With Quote
Old 07-28-2008, 02:40 PM   #6 (permalink)
Neutral Member

82_320i's Avatar

Join Date: Jul 2008
Car:
Posts: 71
Photos:
82_320i is on a distinguished road
Quote:
Originally Posted by Rennsurfer View Post
I bolted them back onto the bumper ends exactly how they came from the factory. I only removed a couple of inches from the center section of the bellows. So, in the end, the bellows are connected at the bumper on the forward end and the rear portion remains attached to the side rubber part where the Hella reflector (now painted black) resides.

Sorry if that doesn't translate correctly. It's easier to show you in person. Guess I should have taken more detailed shots when I was doing that.
oh no dont worry i understand now lol it looks great i think im gunna do it
__________________
SNAKE
82_320i is offline   Reply With Quote
Old 07-28-2008, 03:31 PM   #7 (permalink)
Neutral Member

Rennsurfer's Avatar

Join Date: Jan 2008
Location: Near Mother Ocean, So Cal
Car: 1982 320i 5spd.
Posts: 55
Photos:
Rennsurfer is on a distinguished road
Cool! Good luck and if you can... post up a pic or two.
__________________
Cheers,
Mark
1982 320i 5spd.
1987 Volvo 245DL Estate 5spd.
1967 Volkswagen Beetle 4spd.
Too many surfboards & skateboards to count.

Rennsurfer is offline   Reply With Quote
Old 07-28-2008, 03:51 PM   #8 (permalink)
Neutral Member

82_320i's Avatar

Join Date: Jul 2008
Car:
Posts: 71
Photos:
82_320i is on a distinguished road
ok will do
__________________
SNAKE
82_320i is offline   Reply With Quote
Old 07-28-2008, 08:42 PM   #9 (permalink)
/Banned

Join Date: Jul 2008
Car:
Posts: 12
Photos:
666666 is on a distinguished road
thank you
will do
666666 is offline   Reply With Quote
Old 02-17-2010, 03:06 PM   #10 (permalink)
n00b

MercBimerman's Avatar

Join Date: Feb 2010
Location: Nevada
Car: 93 740iL
Posts: 27
Photos:
MercBimerman is on a distinguished road
Would you happen to know what size nut goes on the inside bumper mounting bracket?
(two on each side).
I just got my 80 320i last week and after inspection behind the bumper, I noticed all of those nuts are missing.

__________________
Past Euros:
80 320i / 85 528e / 86 325 / 88 325 SuperEta / 88 325i 'vert / 89 325ix / 95 525i 5 Spd / 94 740iL
90 MBZ 300ce / 93 MBZ 190e 2.6 / 96 MBZ C280 Sport / 93 MBZ 400e V8 ASR / 91 300TE 4MATIC
94 Alfa Romeo 164LS
98 Land Rover D1 LSE
90 VW Corrado G60 5 Spd
78 Fiat Spyder 124 5 Spd
71 MGB-GT 4 Spd


Some Previous Cars

Last edited by MercBimerman; 02-17-2010 at 03:10 PM.
MercBimerman is offline   Reply With Quote
